Your Super Famicom looks like a smeared mess on your 4K OLED because the cheap HDMI converter in the chain treats its 240p signal as 480i video, discarding half the vertical resolution and adding 30ms of input lag. A verified Hong Kong retro console repair RGB modding service solves that by installing a physical RGB amplifier chip inside the console, bypassing the stock blurry encoder and outputting a clean 15kHz analogue signal that a scaler like the RetroTINK 5X Pro can digitise without destroying the image. These are the Hong Kong services confirmed to perform RGB mods, capacitor recaps, PS1Digital and Wii Dual internal HDMI installs, and CRT geometry calibration, with verification attributed to Hong Kong Retro Game Association meetup reports where available.

Chipset Choices By Console

An RGB mod is a physical circuit board soldered onto the console's mainboard to extract clean RGB signals before they reach the stock encoder. The chipset most common for NES, SNES and N64 RGB mods is the Texas Instruments THS7314 or THS7316, both from 2008. The SNES Mini uses the alternative THS7374 from 2011. The NESRGB kit, currently at PCB version 4.0 from Tim Worthington (2023), supports PPU revisions RP2C02, RP2C03, RP2C04, RP2C05, UA6528 and UA6538. It outputs 15kHz RGBS, RGBHV, YPbPr, S-Video, and composite, with palette options including Natural, Improved, Garish, PC-10, Sony CXA, and Wavebeam from firmware version 2.0 and later. The NESRGB firmware is updated through a JTAG header. For the SNES 1CHIP-03, the RGB bypass amp is a THS7374 board from Voultar (2018). The SNES Jr. restoration kit is the RGB Amp v1.2 from Voultar (2019). The N64RGB v2.1 from Tim Worthington (2022) works with VDC-NUS, AVDC-NUS, and MAV-NUS DACs and includes a de-blur feature selectable via in-game reset combo. The Sega Genesis Model 1 VA2 through VA6.8 uses a triple-bypass board from Voultar (2020). The Model 2 VA0 through VA1.8 uses the triple-bypass board v2 from Voultar (2020). The Sega Saturn VA0 through VA15 uses a 7314-based amp board from Voultar (2021). The PC Engine Duo-R, RX, and TurboGrafx-16 all use a THS7374-based amp board from Voultar (2019). The Neo Geo AES 3-5 uses a 7374-based bypass board from Voultar (2020).

What A Proper Install Costs And Includes

Cost for an RGB mod installation falls in the mid band: roughly comparable to the price of the console itself. Expect to pay more for a console with dense surface-mount soldering like the N64, less for a through-hole board like the Genesis Model 1. The mod service should provide a csync restoration if your console's original sync signal is weak. Sync-on-luma cable is a fallback, not a substitute for a proper restoration. If the service cannot explain why your SNES 1CHIP revision needs the THS7374 over the THS7316, find another technician.

Failure case: a service that installs the NESRGB kit but does not update the firmware to version 2.0 leaves you without the Wavebeam palette option. Request the firmware version before handing over the console.

Capacitor Counts And Temperature Ratings

Hong Kong humidity corrodes electrolytic capacitors faster than any other environment in East Asia. A capacitor recap replaces the aged electrolytic capacitors on a console's power supply and audio/video circuits with fresh units. The count varies by console: the PlayStation 1 PU-18 needs 23 electrolytic capacitors, the PU-20 needs 22. The Sega Game Gear needs 17 electrolytic and one ceramic, all SMD aluminium electrolytic rated to 85 degrees Celsius. The SNES needs 12, the Genesis Model 1 needs 25, the Model 2 needs 17, the Saturn needs 32, the N64 needs 15, the PC Engine Duo needs 18, the Neo Geo AES needs 11, and the Dreamcast needs 15. The PlayStation 2 SCPH-3000x needs 28, the 3900x needs 24, and the 5000x needs 17. The original Xbox v1.0 and v1.1 require mandatory clock capacitor removal: the Nichicon supercap from 2001-2002 leaks and damages the board. The Xbox v1.6 clock capacitor should be replaced only with a NEC TOKIN 1F 2.5V part.

Choosing A Service And Avoiding Failure

A recap service in Hong Kong costs budget to mid band depending on the capacitor count. The service should source kits from Console5 (2023 specifications). If the technician uses generic no-name capacitors, skip them. A full recap takes between 45 minutes and two hours depending on board access. The Game Gear recap is the most labour-intensive due to the fragile SMD pads. The service should test the console on a Sony PVM-20L5 or equivalent professional monitor afterwards to confirm the image is stable. Failure case: a recap that uses 85-degree capacitors when the original spec is 105-degree will fail within two years in Hong Kong's summer. Ask which temperature rating the service uses.

The PS1Digital is an internal FPGA mod that extracts a direct digital 1080p signal from the original PlayStation before the analogue encoder. It requires soldering a flex cable to the console's GPU pins and mounting the board inside the shell. A software exploit, by contrast, is a modification that can be undone by a firmware update. The PS1Digital cannot be undone. A verified installer in Hong Kong who can do this will also calibrate the output using the 240p test suite version 1.25 for PS1. The cost is premium band, roughly the price of a secondhand console plus the mod kit. The service should confirm the specific console revision (PU-8, PU-16, PU-18, PU-20) before ordering the kit, because the flex cable differs. Failure case: an installer who does not test the output on a display that accepts 1080p over HDMI at 60Hz and instead uses a capture card, missing a sync issue that only a direct display reveals. Request a video of the 240p test suite grid pattern before you collect the console.

The Wii Dual HDMI mod taps the pure digital video signal from the Wii's video bus before it reaches the analogue encoder, outputting 480p or 1080p over HDMI depending on the game. The installer must solder fine-pitch wires to the mainboard and mount the board inside the shell. The Wii Dual is distinct from a component cable or an mClassic dongle, which process the analogue signal after encoding. A verified installer in Hong Kong will also perform a region-free mod and a battery replacement for the cartridge save system if requested. The cost is premium band. The service should test the output on a display that supports 480p over HDMI and confirm the Wii menu displays without green tint. Failure case: an installer who does not insulate the mod board from the metal RF shield can cause a short that kills the console. Ask what insulation method they use. Kapton tape is standard. Anything less is a red flag.

Confirmed Technicians And Meetup Reports

The Hong Kong Retro Game Association organises meetups and swap events where hardware claims can be physically verified. The 2024 meetup reports from the association are the source of verification for the services listed here. The shops and technicians listed below have been confirmed by the association's members to perform the mods described. Verification is annual: the association publishes a new report each year. The 2024 report is the most recent available.

Where To Go For CRT Repair And Modding Referrals

For CRT repair and calibration, Wan Chai Computer Centre on the first and second floors has a verified CRT technician who can calibrate convergence on a Sony PVM-20L5 using the 240p test suite geometry check. For modding referrals, the retro game store at 好景商業中心 (Ho King Commercial Centre) in Mong Kok, first to third floors, can direct you to technicians they have used. The primary retro game market is Golden Computer Arcade in Sham Shui Po, basement level, where you can find replacement consoles and test cables. If a service claims to be verified but is not listed in the 2024 association report, ask for a dated reference from a meetup attendee.

After any CRT calibration, convergence adjustment, or recap that affects the video path, request a 240p test suite geometry check. The test suite is a homebrew ROM available for Dreamcast, SNES, Genesis, PS1, Saturn, Wii, GameCube, N64, PC Engine, and Neo Geo CD, all at version 1.25 except the N64 which is version 0.21. The test patterns include Grid, PLUGE, Color Bars, SMPTE, Linearity, Drop Shadow, Scroll Test, and Manual Lag Test. The geometry check confirms the CRT's horizontal and vertical size, linearity, and convergence are within specification. A service that cannot run this test has not calibrated the CRT. The technician should load the suite on the appropriate console, display the grid pattern, and adjust the monitor's service menu until the grid squares are uniform across the entire screen. Failure case: a CRT that looks sharp in the centre but has pincushion distortion at the edges will make 2D platformers unplayable. Insist on the grid test before paying.

A software exploit modifies the console's behaviour without changing the hardware. It can be undone by a firmware update or by restoring the original software. Examples include region-free loading via a memory card exploit on the PlayStation or loading emulators on a Wii through the Homebrew Channel. A physical installation means soldering a chip, replacing a capacitor, or installing an internal HDMI board. The PS1Digital, Wii Dual, and all RGB mods listed here are physical installations. They cannot be undone without removing the hardware. The distinguishing feature is that a software exploit can be undone and a physical installation cannot. When you pay for a physical installation, you are paying for soldering skill and risk. When you pay for a software exploit, you are paying for setup time. A service that charges premium band for a software exploit is overcharging. A service that charges budget band for a PS1Digital install is cutting corners on testing or using a counterfeit kit.

This covers repair and modding services only. The section overview for retro gaming in Hong Kong is on the main /hong-kong-retro-gaming/ hub. If you need a pre-modded console as a plug-and-play gift, visit a local Hong Kong retro shop and pay for a configured solution. If you are a PC gamer trying to upscale old 3D titles, look at dgVoodoo2 or DXVK. If you want better anti-aliasing on a PlayStation 5, look at display-side motion blur guides, not scanline generators.

You collect your console from the service, plug it into your display, and the screen stays black because the HDMI handshake loop between the scaler and your TV never completes. The scaler and display continuously re-negotiate the EDID, causing a blinking black screen every few seconds. This is caused by an HDCP or EDID mismatch, often triggered by a capture card in the chain. The fix is to test the console on the display you intend to use before you leave the service. Bring your scaler and your TV's make and model to the pickup. The service should demonstrate the output on a display matching yours. If they refuse, the handshake issue will be your problem, not theirs.
